Giada DN76 RK3568 2GB DDR4 32GB eMMC Dual-HDMI Arm Player

The Giada DN76 Dual-HDMI Arm Player is a compact yet powerful 4K digital signage media player built for professional environments across South Africa. Powered by the efficient Rockchip RK3568 quad-core Cortex-A55 processor clocked at up to 2.00GHz, this Android 11 device delivers reliable, energy-efficient performance with a low 6W TDP, making it ideal for retail stores, corporate environments, hospitality venues, healthcare facilities and educational institutions. Its advanced ARM Mali-G52 GPU supports OpenGL ES 3.2, OpenCL 2.0 and Vulkan 1.1, ensuring smooth multimedia rendering and stable 4K playback for high-impact advertising and information displays.

Designed with flexibility and durability in mind, the DN76 features dual HDMI outputs, enabling simultaneous multi-display setups with resolutions up to 4096 x 2160 @60Hz on HDMI 2.0 and 2560 x 1440 @30Hz on HDMI 1.4. The fanless metal chassis ensures silent operation and enhanced longevity, even in demanding commercial installations. With onboard Wi-Fi and Bluetooth, optional 3G/4G module support, multiple USB ports including USB 3.2 Gen1, and RS232 connectivity, the DN76 offers seamless integration into modern digital signage networks. Its compact footprint (11.6 x 10.7 x 3 cm) makes it easy to deploy behind displays or in confined spaces, delivering powerful Android-based media playback in a professional-grade format.

FEATURES:

• 4 x Cortex-A55 cores up to 2.00GHz with 6W TDP for energy-efficient, stable performance.


• 4K 60fps H.265 / H.264 / VP9 decoder


• 1080P 60fps H.265 / H.264 encoder


• 1 x HDMI 2.0 (4096 x 2160 @60Hz)


• 1 x HDMI 1.4 (2560 x 1440 @30Hz)


• Supports OpenGL ES 1.1 / 2.0 / 3.2, OpenCL 2.0 and Vulkan 1.1.


• Durable black metal construction for silent, reliable 24/7 operation.


• Onboard Wi-Fi & Bluetooth, reserved 3G/4G module connector, RS232 serial port, USB 3.2 Gen1 and USB 2.0 ports.


• Fanless design for quiet operation

SPECIFCIATIONS:

• CPU: Rockchip RK3568


• Frequency: 2.00 GHz


• Processing units: 4 Cores Cortex-A55


• TDP: 6 W


• System Memory: 2 GB, Onboard DDR4


• Storage: 32 GB, Onboard eMMC


• GPU: ARM Mali-G52


• Graphic Engine:



  • OpenGL ES 1.1/2.0/3.2


  • OpenCL 2.0, Vulkan 1.1






• Multi-Media:



  • 4K 60fps H.265/H.264/VP9 decoder


  • 1080P 60fps H.265/H.264 encoder






• Display Interface:



  • 1 x HDMI 2.0 (Max. 4096 x 2160 @60 Hz)


  • 1 x HDMI 1.4 (Max. 2560 x 1440 @30 Hz)






• I/O interface:



  • USB: 1 x USB3.2 Gen1 (OTG), 1 x USB3.2 Gen1 | 2 x USB2.0


  • Serial Port: 1 x RS232


  • Audio: 1 x 2-IN-1 headset (MIC-IN & AUDIO-OUT)


  • Button: 1 x Power on, 1 x Recovery


  • Antenna: 1 x Connector for Wi-Fi/BT | 1 x Connector for 3G/4G (Reserved)






• Watchdog Timer: NA


• Auto Power On: Yes


• RTC: Set up independently every day, a week as a cycle


• Remo on: NA


• Power Requirement: DC-IN, 12 V/2.08 A


• Construction: Metal, Black


• Operating System: Android 11


• Operating Temperature: 0°C ~45°C (32°F~113°F) @0.7m/s Air Flow


• Certifications: CE, FCC Class B


• Humidity: 95% @ 40°C (non-condensing)


• Colour: Black


• Product Dimensions: 11.6 x 10.7 x 3 cm

WHAT'S IN THE BOX:

• Giada DN76 RK3568 2GB DDR4 32GB eMMC Dual-HDMI Arm Player - Black x1


• AC Power Adapter x1


• AC Power Cable x1
